In the field of home sports equipment, walking MATS have become an important choice for the elderly and novice exercisers due to their low strength and easy operation. However, due to the lack of a supporting structure, ordinary walking MATS significantly increase the risk of imbalance during exercise. According to sports medicine research data, the probability of users of walking equipment without handrails falling is 18.7%, among which the proportion of people over 65 years old and novice exercisers exceeds 72%. The handrail walking mat, through ergonomic design and safety protection mechanisms, builds a safety barrier from three dimensions: support stability, movement adaptability, and emergency protection. This article will comprehensively analyze its core safety advantages by combining technical parameters and scientific principles.
First, support structure design: Build a stable protective net during movement
The core safety value of the handrail walking mat lies in the auxiliary support function of the handrail system for human balance. It needs to be analyzed from three aspects: handrail material, structural parameters, and adjustment function, in combination with ergonomic principles.
1.Handrail material and mechanical properties: Balancing load-bearing capacity and comfort
High-quality handrails must simultaneously meet the dual requirements of load-bearing strength and usage comfort. Industry standards stipulate that the static load-bearing capacity of the handrail should be no less than 150kg, and the dynamic load-bearing capacity (simulating the user’s sudden imbalance when grasping) should be no less than 120kg. Moreover, after 100,000 cycles of load-bearing tests, the deformation rate should be controlled within 0.5%. The common materials for handrails are divided into two categories:
High-carbon steel frame + PU coating: The diameter of the high-carbon steel pipe should be ≥32mm, and the wall thickness should be ≥1.5mm to ensure the bending strength. The density of the outer PU material should reach 0.9g/cm³, and the Shore hardness should be controlled at 60±5HA, which not only avoids hand pressure caused by being too hard but also prevents the support stability from being affected by being too soft.
Aviation-grade aluminum alloy + silicone anti-slip layer: The aluminum alloy handrail adopts 6061-T6 heat treatment process, with tensile strength ≥310MPa, and its weight is only 1/3 of that of carbon steel of the same specification, which is convenient for the overall movement of the equipment. The surface silicone anti-slip layer has a texture depth of ≥0.8mm, a friction coefficient of ≥0.6, and a grip force attenuation rate of ≤15% in a humid environment, reducing the risk of hand slipping.
2. Armrest spacing and height adjustment: To meet the needs of different body types
The spatial parameters of the handrail directly affect the effectiveness of support and must comply with ergonomic size standards. In terms of horizontal spacing, the center distance of the standard handrail should be between 580mm and 650mm, suitable for the shoulder width range of 95% of adults (the average shoulder width of Chinese adults is 370mm to 450mm), to avoid limb restraint caused by being too narrow or inability to grasp in time due to being too wide. The height adjustment function should cover an adjustment range of 100mm to 150mm. The minimum adjustable height should be ≥750mm (suitable for people with a height of 150cm), and the maximum adjustable height should be ≤900mm (suitable for people with a height of 190cm). The interval between adjustment gears should be ≤20mm. Ensure that users of different heights can all find a natural grip position – when the height of the handrail is level with the user’s hip, muscle tension can be reduced by 28% and balance stability can be improved by 40%.
Some high-end products also feature a handrail Angle adjustment function, which can be fine-adjusted within the range of 0° to 15°, adapting to users’ different grasping habits such as natural drooping and slight forward extension, further reducing joint pressure.
3. Auxiliary support details: Reduce the risk of sudden imbalance
Apart from the core handrail structure, the detailed design is of vital importance to safety protection. The end of the handrail should be treated with an arc transition, and the edge chamfer radius should be no less than 5mm to avoid sharp edges causing bumps and injuries. 1 to 2 anti-slip protrusions should be set on the inner side of the handrail, with a height of no less than 2mm, to provide additional friction when the user’s hand slides slightly. Some products also add a transverse stabilizer bar at the bottom of the handrail. The diameter of the bar body is ≥25mm, forming a triangular support structure with the handrail. This increases the overall anti-tilting moment of the equipment by 35% and effectively prevents the equipment from tilting due to single-side force.
Second, optimization of exercise adaptability: Matching the physiological characteristics of the elderly and beginners
The physiological functions (such as muscle strength, cardiopulmonary function, and balance ability) of the elderly and novice exercisers are significantly different from those of regular exercisers. The handrail walking mat achieves safe adaptation through the adjustment of exercise parameters and protective design.
1. Speed adjustment range: Precise control in the low speed range
The walking speed of the elderly and beginners is generally lower and they are sensitive to changes in speed. The speed adjustment range of the walking mat with handrails should cover 0.3km/h to 6km/h. In the low-speed range of 0.3km/h to 2km/h, stepless speed change should be achieved, with a speed fluctuation error of no more than 0.1km/h, to avoid the starting impact caused by the minimum speed being too high (mostly 1km/h) in conventional equipment. Studies show that when the walking speed drops from 1km/h to 0.5km/h, the gait stability of the elderly increases by 52%, and the impact force on the ground of the foot decreases by 23%, effectively reducing the pressure load on the knee and ankle joints.
Meanwhile, the speed adjustment button should adopt a large-sized design (diameter ≥25mm), with anti-slip patterns on the surface and a spacing of ≥30mm, to facilitate precise operation by the elderly or users with poor hand flexibility and avoid sudden speed changes caused by accidental touches.
2. Buffer and shock absorption system: Reduces joint impact damage
The degeneration of articular cartilage in the elderly (the thickness of cartilage in people over 60 is 40% less than when they were younger), and novices lack correct landing cushioning techniques. Both are prone to joint damage due to the impact of hard ground surfaces. Under the running belt with handrails and walking MATS, multiple layers of buffer structures should be set up
Surface buffer layer: Made of high-density EVA material, with a thickness of ≥8mm, a compression rebound rate of ≥85%, and capable of absorbing 30% of the impact force upon landing.
Middle support layer: PP honeycomb structure board is used, with honeycomb pores of 5mm×5mm, which ensures support while further disperses pressure.
Bottom shock-absorbing pad: Made of natural rubber, with a thickness of ≥5mm and a Shore hardness of 45±5HA, it is suitable for different ground hardness levels (such as ceramic tiles and wooden floors), preventing secondary impacts caused by equipment vibrations being transmitted to the ground.
After testing, it was found that a walking mat equipped with a complete cushioning system can reduce the peak impact force on the foot by 45% and the pressure on the knee joint by 38%, significantly lowering the risk of joint injury.
3. Balance assistance function: Real-time correction of gait deviation
The gait stability of the elderly and novices is relatively poor, and they are prone to gait deviations (such as foot inversion or foot valgus) or uneven stride lengths. Some walking MATS with handrails are equipped with a gait sensing system. The pressure sensor (sampling frequency ≥100Hz) under the running belt monitors the position of the foot point in real time. When the gait deviation exceeds 15mm, the device will alert through the vibration of the handrail (vibration frequency 50Hz-80Hz, amplitude ≤1mm). At the same time, the speed will be automatically reduced by 10% to 20% until the gait returns to normal. This function can reduce the risk of imbalance caused by gait deviation by 60%, and is especially suitable for elderly users with weak balance ability.
Third, emergency protection mechanism: Safety guarantee for dealing with unexpected situations
Unexpected situations during exercise, such as physical discomfort or equipment malfunctions, are significant sources of safety risks. The handrail walking mat, through multiple emergency protection designs, enables rapid response to risks.
1. Emergency stop system: Rapid braking with multiple trigger modes
The emergency stop function needs to have multiple trigger mechanisms to ensure that users can quickly stop the device in case of emergencies. The core triggering methods include:
Handrail emergency button: It is set at an easily accessible position at the front end of the handrail. The button color is a striking red, with a diameter of ≥30mm. After being pressed, the equipment should stop running within 0.5 seconds, and the sliding distance of the running belt should be ≤100mm.
Safety key interlocking: Equipped with a magnetic safety key, one end is connected to the user’s clothing and the other end is inserted into the device. When the key disengages from the device, the running belt needs to brake within 0.3 seconds, and the response speed is 40% faster than that of the conventional pull-cord safety key.
Pressure sensing stop: A pressure sensing area (width ≥50mm) is set at the edge of the running belt. When the pressure on one side exceeds 50kg (such as when the user leans towards the edge), the speed will be automatically reduced and a beep alarm will be triggered. If it does not return to normal within 10 seconds, the operation will stop.
2. Overload and overheat protection: Safety redundancy for equipment operation
Equipment failure is also an important factor causing safety accidents. Pedestrian pads with handrails need to have complete overload and overheat protection functions. The overload protection threshold of the motor should be set at 1.2 times the rated power. When the motor load exceeds the threshold, the equipment will automatically cut off power and display the fault code. Motor temperature protection is achieved through an internal temperature sensor (measuring range -20 ℃ to 150℃, accuracy ±1℃). When the motor winding temperature exceeds 120℃, overheat protection is triggered, forcing the machine to shut down for cooling to prevent the risk of fire caused by motor burnout.
In addition, the power cord of the equipment must comply with the IEC 60335 standard, with a wire diameter of ≥0.75mm², and be equipped with a 10A overload protection plug. The grounding resistance of the plug should be ≤0.1Ω to prevent electric shock accidents caused by leakage.
3. Sound and light alert system: Real-time transmission of safety information
The elderly and novices have a relatively weak ability to perceive the status of equipment, and it is necessary to enhance the transmission of safety information through sound and light prompts. When the equipment is in operation, it should have:
Speed display: It adopts LED digital tube display, with a digital height of ≥25mm and a brightness of ≥300cd/m², ensuring that the elderly can clearly see it within a range of 3 meters.
Fault alarm: Different fault types correspond to different frequencies of beeping prompts (for example, 1 beeping per second for abnormal speed and 2 beeping per second for excessively high temperature), and are accompanied by the flashing of a red fault indicator light.
Operation guidance: When used for the first time, it automatically plays voice guidance (supporting multi-language switching), indicating the grip method of the handrail, speed adjustment method and emergency stop operation. The voice volume can be adjusted within the range of 50dB-80dB, suitable for users with different hearing conditions.
Fourth, extended application scenarios: Meeting diverse security requirements
The safety design of the handrail walking mat is not only suitable for regular walking activities, but can also be extended to rehabilitation training, daily assistance and other scenarios, further enhancing its usage value.
1. Rehabilitation training adaptation: Assisting postoperative recovery
For people recovering from joint surgery (such as knee replacement surgery), walking MATS with handrails can be used as low-intensity rehabilitation training equipment. By running at an ultra-low speed of 0.3km/h to 1km/h and with the stable support of the handrails, users can perform gait training within a safe range and gradually restore muscle strength and joint range of motion. Some products also support connection to rehabilitation apps, which record gait data (such as cadence, stride length, and landing Angle) through sensors on the handrails, providing training assessment basis for rehabilitation therapists and enhancing the safety and pertinence of rehabilitation training by 40%.
2. Daily auxiliary functions: Enhance the convenience of use
Considering the daily usage needs of the elderly, the handrail walking mat can be designed with additional auxiliary functions. For instance, a water cup holder (with a load capacity of ≥500g and a diameter of 70mm-90mm) is added to the side of the handrail to prevent imbalance caused by users bending over to fetch water. The top of the handrail is equipped with a flat plate bracket (adjustable Angle 0°-60°), supporting the fixation of flat plates within 10 inches, which is convenient for users to watch teaching videos or entertainment content and reduces the distraction of attention during movement. Some products also add mobile wheels (with a diameter of ≥50mm and braking function) at the bottom of the device. Combined with the assist design of the handrails, the force required for device movement is reduced by 60%, making it convenient for the elderly to independently adjust the position of the device.
The handrail walking mat precisely addresses the safety concerns of the elderly and novice exercisers through optimized support structure, sports-adaptive design and emergency protection mechanism. Its core value lies not only in reducing the risk of falls, but also in enhancing users’ confidence in exercise through scientific design – data shows that the exercise persistence rate of elderly people using handrails on walking MATS is 65% higher than that of those using ordinary walking MATS, and the exercise frequency of beginners also increases by 38%. When choosing home exercise equipment, safety is always the top priority. The handrail walking mat, with its deep adaptation to the physiological characteristics of specific groups of people, has become an ideal choice that combines safety and practicality, providing more people with a safe and convenient home exercise experience.
