In the treadmill industry, whether for commercial or home models, one of the most frequently asked and vexing questions from customers is not about motor power or features, but rather: “Does this machine actually protect the knees?” Behind this question lies end-users’ widespread fear of joint injuries, as well as the practical pain point of a poor workout experience and abandoned equipment caused by inadequate shock absorption. As industry practitioners, we must understand that a treadmill’s shock absorption system is not just a “value-added” feature, but a critical factor that defines a product’s core value and user retention rate. This article will thoroughly explain how an effective treadmill shock absorption system works, and how you can use this fundamental knowledge to clearly communicate its value to customers—whether gym buyers or home users—thus turning technical advantages into clear grounds for purchasing decisions.

Shock absorption on a treadmill is not simply about making the running feel softer; its fundamental goal is to scientifically manage impact forces. When a person runs, the impact force generated with each step can reach 2 to 3 times their body weight. If this energy is directly transmitted back to the knees, ankles and spine through a rigid running deck without any mitigation, the long-term accumulation becomes the primary cause of joint strain. The physical logic of an excellent treadmill shock absorption system lies in achieving two things through a carefully designed “cushioning-rebound” cycle: first, extending the duration of the impact force (absorbing energy through deformation), and second, changing the direction of the impact force (converting part of the vertical impact into horizontal or dispersed energy).

Simply put, it’s like installing a set of intelligent springs and dampers between the hard concrete floor and your joints. It delivers a feeling of “supported softness”, rather than the energy-dissipating sensation of “stepping on sand”. For commercial gyms, this means a lower risk of member injuries and higher equipment utilization rates; for home users, it directly determines whether they can stick to their workouts, instead of giving up after a few runs due to knee soreness.

Industry Case Reference: A renowned high-end home treadmill brand from Northern Europe centers its shock absorption technology on a combination of multi-layer elastic pads beneath the running deck. Their user data shows that for models equipped with this system, in follow-up surveys of users with mild knee discomfort, the proportion of feedback stating “significant reduction in pain” was over 40% higher than that of competitors using ordinary rigid running decks. This has become the most powerful demonstration segment in their offline experience stores.

User Q&A: “Will a shock absorption system reduce workout effectiveness or make running too easy?” This is an excellent question and a common misconception among consumers. An effective shock absorption system absorbs harmful, high-frequency joint impact forces, rather than offsetting the work your muscles do to propel your body forward. A superior system provides vertical cushioning while maintaining sufficient horizontal rebound to push you into your next step. It protects joints without “cutting corners”, and can even allow you to run longer and safer, thereby increasing your total workout volume.

There are numerous types of treadmill shock absorption technologies on the market, but their core mechanical structures can be categorized into several major types. Understanding their differences is the foundation for accurate product recommendations.

Elastic Silicone/Rubber Column (Shock Absorption Module) System: This is the most common and cost-effective solution. Multiple high-density elastic silicone or rubber columns are placed at key stress points under the running deck (e.g., both sides and the middle). Its principle is similar to the rubber bushings in automotive shock absorbers, absorbing impact through its own compressive deformation. Advantages include a simple structure, durability, and well-defined cushioning points. Disadvantages are relatively fixed cushioning performance, and potential uneven running feel if poorly designed.

Air Cushion Shock Absorption System: Can be regarded as an “adjustable” upgraded version of elastic columns. Cushioning is provided by inflatable air bladders embedded under the running deck. Advantages include the ability to personalize the firmness to a certain extent by adjusting air bladder pressure, offering greater adaptability. Disadvantages include the risk of slow air leakage with long-term use and higher costs. This technology is adopted in some high-end commercial models.

Suspension Shock Absorption System: This is usually a more systematic solution, mimicking automotive suspension. The running deck is not directly fixed to the base frame, but connected via a set of linkages with springs and dampers. Advantages include more linear, holistic cushioning, a running feel closer to a high-quality synthetic track, and effective dispersion of impact forces. Disadvantages include a complex structure, high cost, and slightly larger space occupation, making it common in mid-to-high-end home and commercial models.

Combined Shock Absorption System: The current trend for mainstream mid-to-high-end products. Examples include a “silicone column + elastic running deck” combination, or a “suspension system + front air cushion” combination. Through the synergy of multiple technologies, it strives to achieve the optimal balance between cushioning, rebound and stability.

User Q&A: “As a buyer, how can I easily and quickly experience the differences between different shock absorption technologies?” The most direct method is the “barefoot jog comparison test”. Jog on different treadmills at the same speed (e.g., 6 km/h) wearing thin-soled shoes or barefoot. Focus on feeling: the degree of “hardness” the moment the sole touches the deck; whether the running deck has an overall sinking sensation with each step; and the difference in comfort in the feet and knees after running. The differences are often very noticeable.

When discussing shock absorption systems, many people only focus on the structures beneath the running deck, ignoring the deck itself—it is the first component your foot touches, and the first line of defense for shock absorption. The material, thickness and structural design of the running deck are crucial.

Currently, mainstream high-end treadmills generally adopt a multi-layer composite running deck. The top layer is usually a wear-resistant vinyl or similar material, the middle layer is a high-density fiberboard (providing stable support), and the core is the key—one or more layers of elastomer materials (e.g., special rubber or polymer composite materials). This composite running deck itself has a certain degree of “flexural elasticity”. When your foot lands, it undergoes slight deformation, pre-absorbing a portion of the impact force before transmitting the remaining energy to the underlying shock absorption system for secondary processing.

A high-quality elastic running deck, paired with a bottom shock absorption system, can create a “synergistic shock absorption” effect. Conversely, a thin, rigid running deck, even with shock absorption modules underneath, can easily give users an uncomfortable “stepping on wood” feeling, and the peak impact force remains high.

Industry Case Reference: An internet fitness brand focused on online sales once conducted an A/B test. They provided test users with two models with almost identical configurations except for the thickness and material of the running deck. The results showed that the model with a thicker, more elastic composite running deck received a 28% higher score for “knee and ankle comfort”, and the product return rate was reduced by more than 15%. This directly proves the weight of the running deck itself in the user experience.

User Q&A: “Is a thicker and softer running deck always better?” Not necessarily. An overly thick and soft running deck leads to excessive energy loss, making running strenuous, and may affect stability due to excessive deformation—even posing a safety hazard. The ideal state is “toughness” rather than “softness”, i.e., providing sufficient cushioning while maintaining adequate rebound support and structural rigidity. This requires a precise balance of material and structural design.

As a professional buyer or seller, you need to translate technical jargon into customer-understandable value propositions.

For home users/end consumers: Avoid piling up technical terms. Use scenario-based descriptions: “Our six-point silicone suspension system is like putting six small air cushions under the running deck. It cushions the impact on your knees with every step, so your knees won’t be sore the next day after running, making it easier to stick with your workout.” Emphasize “protection”, “comfort” and “persistence”.

For gym/commercial buyers (B2B): Focus on return on investment (ROI) and risk management. Communicate like this: “This multi-stage shock absorption system not only improves member workout comfort and safety, directly reducing the risk of exercise injuries caused by equipment (one of the biggest legal and reputational risks for gyms), but also significantly reduces structural fatigue of the equipment caused by long-term high-intensity impact, extending the service life of key treadmill components and lowering your long-term maintenance costs.” Emphasize “safety”, “durability” and “lower total cost of ownership”.

Provide verifiable experiences: No matter how you describe it, an on-site experience is worth a thousand words. Ensure your display space allows customers to run on the treadmills themselves and feel the differences.

Ultimately, an excellent treadmill shock absorption system is engineering’s in-depth response to human biomechanics. Through the synergy of running deck materials, cushioning structures and overall design, it converts destructive impact forces into controllable, dispersed energy, thus safeguarding runners’ joint health from the source. For industry practitioners, a deep understanding of its working principle is not just for answering technical questions, but for accurately matching user needs—turning a core technology hidden beneath the equipment into the most persuasive product competitiveness and the cornerstone of customer trust. After all, a piece of equipment that allows users to run safely, comfortably and for the long term is a truly viable and great product.



A: Yes, this is a normal wear process. In particular, elastic components such as silicone columns and rubber pads will gradually experience plastic deformation or aging due to long-term repeated compression, leading to reduced elasticity. High-quality products use more durable materials (e.g., high-grade polyurethane) and design key shock absorption components as replaceable modules to extend the overall service life of the treadmill. This is a point that requires special attention for commercial models.

A: The heavier the user, the higher the requirements for the shock absorption system. Prioritize models with a more robust shock absorption structure, a thicker running deck and a higher rated load capacity. Suspension or combined shock absorption systems can generally disperse larger impact forces more evenly than simple point-type silicone pads. Be sure to ensure the stated maximum user weight of the selected model has a sufficient margin (it is recommended to be at least 20% higher than the user’s body weight).

A: For most home users who mainly walk and jog, a reliable shock absorption system is more important than pursuing excessively high motor power when on a budget. A continuous motor power of 2.0 CHP is sufficient to support the use of the vast majority of home users, while poor shock absorption leads to physical discomfort that directly results in equipment being left unused. Investing in the basic experience of body protection first is usually a wiser choice. Of course, the optimal solution is a balance between the two.
